blu™ LP400 Sleeve Letter Plate (KITS)
Product Ref: LP400
Finest quality letter plate complete with gaskets, brushes, telescopic liner and a built-in security flap for enhanced security and weather protection. Manufactured from 316 Marine Grade Stainless Steel it will survive in even the most extreme environments such as exposed coastal locations etc. Add to this styling which suits contemporary or classic heritage design and you have a letter plate which is in high demand.
Weather Tested to BS6375-1, Successfully used in PAS24 Test.
The LP400 is designed to fix using bolts from the inside meaning the product cannot be removed from the outside. The fixing bolts supplied will suit door thicknesses of between 44mm - 68mm, please make sure you select the correct kit from below. The internal telescopic liner can also be modified to enable fitting of it on a door thickness of 38mm, please check the drawing.
Available in Super Satin, Mirror Polished or PVD Brass finishes. PVD Brass & Oil Rubbed Bronze versions has a base material of 304 stainless steel.
Please click to download the Technical DWG drawing or click to download the Technical PDF drawing or click to download the DataCard.
|Test Element||Classification||Test method||Result||Class|
|Air Permeability||BS EN 12207:2000||BS EN 1026:2000||600 Pa||4|
|Water Tightness||BS EN 12208:2000||BS EN 1027:2000||600 Pa||A9|
|Wind Resistance||BS EN 12210:2001||BS EN 12211:2000||3000 Pa||5|
To view the items provided within the kit click on the "Click Here" under the Details column.
