Securefold Pro - Top Hung External Folding Door System
SECUREFOLD PRO
Top Hung Folding Door System
The ultimate exterior bifold door hardware system for doors weighing up to 100kg.
|  |
 | The R-Loc – Making the installer’s life a lot easier and featured on the Securefold Pro Folding Door System. R-Loc is a clever ratchet system that enables installers to easily heighten or lower a door, eliminating the process of locking the hanger in place with a grub screw. |
Available in four finishes.
|  |
| Specification | Door Leaf Detail |
|---|---|
|
|
Specification
- Use: Internal or External
- Type: Bottom Rolling
- Opening: Outward
- Joinery Type: Non-Mortice
Door Leaf Detail
- Max Leaf Weight: 100kg
- Max Leaf Width: 1000mm
- Max Leaf Height: 33000mm
- Leaf Thickness: 35 - 68mm
No need for you to take the time to work out what components you need, just fill in the enquiry form and we’ll sort it for you.
Fitting instructions and drawings for the Securefold Pro range can be found here:
Securefold Pro Pricing example
Prices may vary but the table below gives an idea of prices for an outward opening Securefold Pro bifold door, including all hanging components, tracks, weatherseal and bolts.
Finishes: SSS, PSS & PPB
| Door Configuration | Height of Opening (mm) | ||
|---|---|---|---|
| Less than 2200 | 2201 - 2500 | 2501 - 3300 | |
| 2+0 | £495 | £545 | £559 |
| 3+0 | £559 | £605 | £625 |
| 4+0 | £839 | £899 | £935 |
| 5+0 | £959 | £1015 | £1075 |
| 6+0 | £1235 | £1325 | £1375 |
| 4+4 | £1705 | £1819 | £1889 |
| 5+5 | £2075 | £2209 | £2295 |
| 6+6 | £2455 | £2605 | £2709 |
Finishes: BK
| Door Configuration | Height of Opening (mm) | ||
|---|---|---|---|
| Less than 2200 | 2201 - 2500 | 2501 - 3300 | |
| 2+0 | £545 | £615 | £635 |
| 3+0 | £625 | £695 | £715 |
| 4+0 | £945 | £1039 | £1079 |
| 5+0 | £1075 | £1169 | £1229 |
| 6+0 | £1389 | £1535 | £1595 |
| 4+4 | £1985 | £2175 | £2255 |
| 5+5 | £2305 | £2545 | £2645 |
| 6+6 | £2755 | £3019 | £3145 |
Finishes Explained
SSS = Satin Stainless Steel
PSS = Polished Stainless Steel
PPB = PVD Polished Brass
BK = Black
Prices shown here are intended as a guide only and are subject to change without notice. To get a full and accurate quote, simply click here to request a quote.
